A sticker on the unit indicates it was last calibrated a year ago. We currently have no mainframe to test the unit, we have to sell it against DOA only. The 80C03 module supports waveform compliance testing of both short and long wavelength (700-1650 nm) signals at 1.063, 1.250, and 2.488 Mb/s, as well as general purpose testing with up to 2.3 GHz optical bandwidth. Its amplified optical to electrical converter design enables the user to examine very low-level optical signals. The 80C03 can be optionally configured with clock recovery (Opt. CR) that supports Fibre Channel 1063 (1.063 Gb/s), Gigabit Ethernet (1.250 Gb/s) and OC48/STM16 (2.488 Gb/s) standards. This unit has the following applications: * High-Speed Optical Communications Testing * Extinction Ratio and Q-Factor Measurements * Eye-Pattern and Pulse Shape Analysis * Relaxation Oscillation Testing This unit has the following specifications: * Effective wavelength range: 700 nm to 1650 nm * Calibrated wavelengths: 780 nm, 850 nm, 1310 nm and 1550 nm * Clock recovery (Optional): 1.0625 Gb/s, 1.2500 Gb/s, 2.48832 Gb/s, 2.5000 Gb/s * Absolute maximum non-destructive optical input: 5 mW average power; 10 mW peak power at wavelength with highest relative responsivity * Internal fiber diameter: 62.5 µm/125 µm multi-mode * Optical return loss: > 14 dB (62.5 µm multi-mode), > 24 dB (9 µm single mode) * Minimum optical bandwidth: > 2.3 GHz (2.5 GHz, typical) * Fiber input accepted: single- or multi-mode (please look at our rules and privacy policy) |
