QTY 6 ABSOLUTE PRESSURE MILLIMETERS OF MERCURY GAGE EACH GAGE SELLS NEW FOR OVER $2000! http:// /ShopSite/apgs3006.html Standard Features Size: 6" dial Scale length: 16" Range: To 30 psia Accuracy: 0.33% of full scale Sensitivity: 0.2% of full scale Case pressure and volume: 15 psig maximum, 395 cc volume with an optional, overpressure relief valve available to protect the case. Maximum case leak rate: Will not exceed 1.44 x 10-5 std cc/sec or 0.0019 psi/hr. Case connection: 1/8 inch female NPT with built-in stainless steel filter. Connection located on back of case. Case construction: Forged aluminum with tempered glass dial covers. Flush mounted by three screws through the bezel. Material exposed to measured gas: Aluminum, beryllium copper, brass, stainless steel, nylon, E.P.R. Monel, lead, nickel-plated phosphor bronze, soft or silver solder, synthetic sapphire, paper, epoxy cement, TFE, nickel silver, nickel plating, drawing ink, Duco lacquer. Click picture to see actual image size. (please look at our rules and privacy policy) |
russell_curtis@machine--tools.com (Russell Curtis) for additional information. This email is used for forwarding to newsgroup user.
