450V+ 10 meter HF Linear Amplifier Assembly Manual w/ CD ROM This is the comprehensive assembly instruction manual, and CD ROM that is used when assembling the PowerPlate Performance 450V+ 10 meter HF linear amplifier. The manual contains a complete parts list of components, step by step instructions on assembly, and tips on procedures and tools used. The CD ROM contains 131 high definition color photographs that are referred to as you progress through the assembly manual. The CD ROM also contains color schematics, a basic kit builder’s guide, and an additional copy of the assembly manual. With this high quality amplifier, you not only get to have all the fun of construction, but you get bragging rights of giving birth to something you built with your own two hands. Transistor Complement: 1 x SD1446 / 2 x 2SC2879 -Input Transformer: ½ “x ½†w/ #20 Teflon windings. -Output Transformer: ½†x 1†w/ #16 Teflon windings. -Input Transformer: ½†x ½†w/ #16 Teflon windings. -Output Transformers: ½†x 1-1/4†w/ #16 Teflon windings. • Size: 7-3/8†x 4-7/8†x 3-3/8†-Forced air positive pressure ducted cooling. -Continuously variable output control. -Remote control jack (3 styles of remotes available.) -.060†Heavy-duty brushed aluminum cabinet. -Ultra Bright Blue power “ON†LED • Power Output: 200W RMS / 600W PEP @ 15 VDC • Current Draw: 30.3A @ 15 VDC • Input Signal: 2~4W CW / 30W PEP • Frequency Range: 10 meter amateur band. (please look at our rules and privacy policy) |
