SPECS: *** Form Factor is Benchtop *** Bandwidth is 500MHz *** # of Channels is 4 channels *** Simultaneous Channels is 4 channels *** Sim. Max. Sampling Rate/ch is 500 MSa/s *** One Ch. Only Max. Sampling Rate is 2 GSa/s *** Min. Vertical Sensitivity is 2 mV/div *** Max. Vertical Sensitivity is 5 V/div *** # of Bits is 8 bits *** Input Impedance is 1 MOhm *** Input Impedance (alternate) is 50 Ohm *** Input Coupling is AC, DC *** Max. Input Voltage is 250 Vrms *** Max. Input #2 (for Impedance #2) is 5 Vrms *** Main Time Base - Lowest is 1 ns/div *** Main Time Base - Highest is 1000 s/div *** Timebase Accuracy is 0.0003% *** Trigger Source is External *** Trigger Modes is Auto, Normal, Pattern Pulse, Single Stop, TV. *** Min. Trigger Holdoff is 10 ns *** Trigger Sensitivity is 5 mV *** Min. Glitch Trigger is 1 ns *** Display Type is CRT Monochrome *** Display Size is 22.86 cm *** Display Modes is Normal, Persistence, Variable, X/Y. PROGRAMMABILITY / CONNECTIVITY: *** User Interface Proprietary *** Ports to Peripheral Devices GPIB, RS232 *** Test Pattern Storage 4 Patterns. Just the scope is selling on other websites for $3,700.00 and more. Reasonable offers are always well come. REASONABLE ONES! (please look at our rules and privacy policy) |
n_chase@machine--tools.com (Naomi Chase) for additional information. This email is used for forwarding to newsgroup user.
