Tescom PV71LK-L060-162 High Purity Diaphragm Valve New Model: PV71LK-L060-162 Ultra-High Purity Diaphragm Valve Specifications (includes Data Plate information if applicable): * Actuator Type: 1/4 Turn Knob * Materials in contact with media: * Body: 316L VAR Stainless Steel * Remaining parts: 316 Stainless Steel * Certified maximum inboard leak rate: * Seat: 4 x 10-9 atm cc/sec He * Diaphragm: 1 x 10-9 atm cc/sec He * Internal surface finish: .10 Ra or 5 Ra microinch (.25 or .13 micrometer) * PCTFE seat: -40°F to +140°F (-40°C to +60°C) * Internal volume (1/4" tube, 3.00 end to end): Cv .17 = 1.72 cc * Wetted surface are (1/4" tube, 3.00 end to end): Cv .17 = 1.72 cc * Welded Fittings: Tube stubs or VCR® (or compatible) welded to the valve body. * Cleaning: All PV70 Series Valves are DI water electronic grade cleaned. In addition, PV70 Series valves with the Precision Electro- Polish (P.E.P.) are ES 500 Particle Certified. Overall Physical Condition: New in original sealed package. Pictures of contents are from a previous unit of the same model. Notes: Includes safety, installation, and operation precautions documentation. Does not include any additional parts, cables, or documentation. For computer and industrial accessories, the following applies: * Hard drives are checked in Fdisk and checked to see if recognized in BIOS and then erased/DoD wiped. No other implied condition is represented by the description above. Any preinstalled software on the hard drive(s) is removed. This includes any Operating System (Windows). * Money Orders. All Money Orders must be drawn from a US Bank. We do not accept Money Orders drawn from a Non-US Financial Institution. * Cash. This will only be accepted if paying for the item in person. Our offices are open from 9am-4pm Central Time Monday Through Friday. We are closed on the weekends. Please allow 1-3 business days to reply to all e-mails. (please look at our rules and privacy policy) |
