QTY-1 W1702 SHOP FOX SHAPER WITH 2 YR MFG WARRANTY This full-capacity 3 HP Shaper will handle the smallest profile cutters all the way up to the largest panel cutters with its three spindle sizes, 3" spindle travel and 5-1/2" maximum spindle opening. Two reversible speeds also provide the greatest flexibility for arranging cutters of all sizes. So, no matter what the shaping application is, whether it's simple edge profiling or making door stiles, rails and panels, this is the right machine for the job. * Motor: 3 HP, 220V, single-phase with reversing switch * Spindles: 1/2", 3/4" and 1" (Included) * Large precision ground cast-iron table * Table size: 30-1/2" deep x 28-1/4" wide * Magnetic switch with thermal overload protector * Shielded and lubricated ball-bearings * Floor-to-table height is 34" * Spindle speeds: 7,000 & 10,000 RPM * Spindle openings: 1-3/8", 2-3/4", 4" & 5-1/2" * Large handwheel elevates the spindle for precise control and spindle lock knob ensures consistent results * Heavy, cast-iron assembly adjusts both independently for full edge profiling, and in unison for incremental cutting of very large profiles * Starting pins allow irregular shaping * Magnetic switch with thermal overload protects the operator and machine * Interchangeable spindles are easily installed or removed * Removable table inserts provide work support close to the cutter POWERMATIC JET DELTA AND SHOP FOR DISTRIBUTORS VISIT US AT THE SHOP FOX BOOTH AT IWF SHOW IN ATLANTA (please look at our rules and privacy policy) |
