Operation of the various functions is easy and the LCD is a highly readable. Both standard and nonstandard repeater offsets are supported. The full featured DJ-C7T provides over 300 mW of efficient output with the supplied EBP-58 lithium battery. The power jumps to 500 mW when operating from external 6 VDC. The built-in speaker makes this little radio sound big! TX/RX: 144-147.995MHz/420-449.995MHz RX: 88.1-107.995/108-173.995/380-511.995MHz AM/FM/WFM TX/RX: 144-145.995MHz/430-439.995MHz RX: WFM/FM/AM (where permitted) Double Conversion Super-heterodyne (WFM: Single CSH) Auto/5/6.25/8.33/10/12.5/15/20/25/30/50/100/125/200KHz 200ch with 5 PS pairs, 1 priority and 1 auto-repeater pair 300mW with EBP58N / 500mW with 6Vdc power-source -7 to +3ppm (-10 ~ + 50 degrees C.) Ham-bands VHF: -14dBu UHF: -12dBu / WFM -3dBu average +/-12KHz or more(-6dB) +/-35KHz or less (-60dB) 1st: 50.85MHz(WFM 10.7MHz) 2nd: 450KHz 100mW or more (MAX), 90mW or more (10% dist. 8 ohm) at 6.0Vdc 3.7Vdc EBP58N / 3.7 - 6.0Vdc external power source TX: 320mA / RX (squelched): 70mA / RX (BS-on): 19mA -10 ~ +60 degrees C, 14 ~ 140 degrees F 56(W) x 96(H) x 14.5(D)mm (without projections) approx. 102g or 3.59oz antenna/EBP58N inclusive · All item prices include GST. · While all care is taken, any errors or omissions in the item details is unintentional. · Dispatch of goods will be arranged through us. · Please allow up to 5 working days for delivery within Australia and 14 days internationally, although in most cases delivery is much quicker. · If problems do arise, please contact us , and we will endeavour to resolve any issues. (please look at our rules and privacy policy) |
