Now includes ALL Interface Cables! The LDG AT-100 Pro is the next step in the evolution of the automatic tuner. This desktop tuner covers all frequencies from 1.8 – 54 MHz, and will automatically match your antenna in no time. It features a two-position antenna switch, allowing you to switch instantly between two antennas. The AT-100Pro requires just 1 watt for operation, but will handle up to 125 watts, making it suitable for everything from QRP to a typical 100 watt transceiver. The AT-100Pro includes over 2,000 memories for each antenna, automatically storing tuning configurations for each frequency and band as you use them. Frequency sensing circuitry lets the AT-100Pro “know†your operating band and frequency. Whenever you transmit on or near a frequency you’ve used before, the AT-100Pro can retune from memory almost instantly. Rugged and easy-to-read LED bargraphs show power and SWR, and a Function key on the front panel allows you to access data like mode and status. The AT-100Pro uses latching relays which retain the tuned configuration indefinitely even when powered down; current draw when not tuning is effectively zero. The AT-100Pro uses LDG’s state-of-the-art processor-controlled Switched-L tuning network. It will match dipoles, verticals, inverted-Vees or virtually any coax-fed antenna. With an optional LDG balun, you can also use longwires or antennas fed with ladder-line. Control from the front panel is simple and straightforward; just press Tune while transmitting a carrier, and the AT-100Pro will begin an automatic tuning cycle. * 1 to 125 watt power range (SSB and CW), 100W on 6M. * Easy to read LED bargraph display for RF power, SWR and status. * Over 4200 memories for instantaneous band changing. * Two position antenna switch. Separate memories for each antenna. * Tuning time: 0.5 to 6 seconds full tune, 0.2 sec memory. * Selectable user parameters: Auto/Semi, 125/12.5 watt scale, power save and more. * 1.8 to 54.0 MHz coverage. Built-in frequency sensor. * Tunes 6 to 1000 ohm loads (16 to 150 on 6M), 6 to 4000 ohms with optional 4:1 Balun. * For Dipoles, Verticals, Vs, Beams or and Coax Fed Antenna. * Optional external Balun allows tuning of random length, long wire or ladder line fed antennas. * NEW! Interfaces for Icom and Yaesu INCLUDED! * Power requirements: 11 to 16 volts DC at 500 mA Max. * Small Size Enclosure: 7.5†x 5.5†x 2.0â€. ********************************* · Click on your zip code above to quote on multiple items. Before Purchasing from Us – Please read the following! Click here to add The K1CRA Radio Store to your Favorite Sellers (please look at our rules and privacy policy) |
