Atmel ARM7 & Xilinx CPLD SBC development kit OPX-1001 The board has Atmel ARM microcontroller AT91SAM7S256 and Xilinx XC9536XL CPLD Includes FREE JTAG debug cable (LPT port) and Mini USB cable!! The JTAG cable can be used with most IDE's available such as Eclipse + GCC, IAR Embedded Workbench, CrossWorks for ARM etc. The Xilinx CPLD design tool (ISE WebPACK) can be downloaded for free from Xilinx website. It has everything you need to design, test and implement CPLD logic. Visit our site for more products and updates 1. ATMEL AT91SAM7S256 16/32 bit ARM7TDMIâ„¢ CPU core with 256K Bytes Program Flash, 64K Bytes RAM 4. On-board JTAG programmable Xilinx XC9536 CPLD 5. Programmable PLL output clock connected to CPLD 6. On-board Real Time Clock with battery backup 7. Two RS232/RS485 serial ports 8. Up to five channels 384 kbps A/D converter 11. USB 2.0 Full speed device port 12. On-chip Power Management Controller 17. JTAG 10 pin connector for CPU debugging, flash and CPLD programming 18. Ability to debug and run programs from RAM or FLASH 19. Two double row 40 pins 2mm header connectors providing external access to the most CPU pins and all CPLD pins 20. Two on-board voltage regulators: 3.3V and 5V DC 21. Power supply and status LEDs 23. Small form factor 1.6 x 2.4" ( 41 mm x 61 mm) * JTAG debug cable (wiggler compatible) * CD with manual, source code and tools (please look at our rules and privacy policy) |
