This is a BRAND NEW, never opened or built kit. Norcal 38 special for 30M CW. The "38 Special" is a superhet transceiver for the 30M band. The first thing you'll notice looking at the schematics is the lack of discrete transistors. I have been playing with this concept for some time and the 38 Special was the right vehicle. The transmit section relies on a TTL buffer. I extended this concept to utilize the same TTL chip for other tasks. Although it's an NE602-based superhet transceiver, the "38 Special" incorporates only two NE602s. I reuse the product-detector as the transmit mixer by channeling different signals to that chip on receive and transmit. Also, the traditional LM380/386 is gone in favor of a more versatile dual op-amp circuit for the audio section. (please look at our rules and privacy policy) |
